# 10.1. Introduction to 2D Arrays¶

Arrays in Java can store many items of the same type. You can even store items in **two-dimensional** (2D) arrays which are arrays that have both **rows** and **columns**. A **row** has horizontal elements. A **column** has vertical elements. In the picture below there are 3 rows of lockers and 6 columns.

Two dimensional arrays are especially useful when the data is naturally organized in rows and columns like in a spreadsheet, bingo, battleship, theater seats, classroom seats, or a picture. In battleship, letters map to the rows (A is the first row, B is the second row, and so on) and the column indices start with 1.

# 10.2. Array Storage¶

Many programming languages actually store two-dimensional array data in a one-dimensional array. The typical way to do this is to store all the data for the first row followed by all the data for the second row and so on. This is called **row-major** order. Some languages store all the data for the first column followed by all the data for the second column and so on. This called **column-major** order.

## 10.2.1. How Java Stores 2D Arrays¶

Java actually stores two-dimensional arrays as arrays of arrays. Each element of the outer array has a reference to each inner array. The picture below shows a 2D array that has 3 rows and 7 columns. Notice that the array indices start at 0 and end at the length - 1.

On the exam assume that any 2 dimensional (2D) array is in row-major order. The outer array can be thought of as the rows and the inner arrays the columns. On the exam all inner arrays will have the same length even though it is possible in Java to have inner arrays of different lengths (also called **ragged arrays**).

**Check your understanding**

Try to answer the following questions. Click on the value or values to select them. Click again to unselect a value.

8 | -2 | 3 | -1 |

4 | 5 | 0 | -7 |

2 | -3 | -4 | -5 |

8 | -2 | 3 | -1 |

4 | 5 | 0 | -7 |

2 | -3 | -4 | -5 |

8 | -2 | 3 | -1 |

4 | 5 | 0 | -7 |

2 | -3 | -4 | -5 |

8 | -2 | 3 | -1 |

4 | 5 | 0 | -7 |

2 | -3 | -4 | -5 |

8 | -2 | 3 | -1 |

4 | 5 | 0 | -7 |

2 | -3 | -4 | -5 |
